Introduction

The vCloudPoint zero client (also called ultra-thin client) contains no moving parts but only the necessary hardware & firmware to initialize a conversation with the network, begin network protocol processes, and display desktop output. It centralizes all software, processing, and management to just what is running on the host, leaving little more than a keyboard, mouse, and monitor at a user’s desk. As a result, it requires no driver to install, no patch management, and no local operating system licensing fees or updates. The device consumes very little power and is tamper-resistant and completely incapable of storing any data locally, providing a more secure endpoint.

Introduction

The vCloudPoint zero client (also called ultra-thin client) contains no moving parts but only the necessary hardware & firmware to initialize a conversation with the network, begin network protocol processes, and display desktop output. It centralizes all software, processing, and management to just what is running on the host, leaving little more than a keyboard, mouse, and monitor at a user’s desk. As a result, it requires no driver to install, no patch management, and no local operating system licensing fees or updates. The device consumes very little power and is tamper-resistant and completely incapable of storing any data locally, providing a more secure endpoint.

Easy to set-up, Use & Manage

vCloudPoint zero clients are extremely easy to set up, use and manage. There is only the vMatrix Server Manager or the Virspire Desktop Agent to run on the system. The software installation is so easy in just one click. There are no configurations needed to be done at the endpoints or the host. The vCloudPoint zero client provides a plug-and-play experience to users. The software interface is user-friendly and much intuitive for any untrained IT staff to manage at ease.

Smooth Desktop Experience

Powered by vCloudPoint’s innovative Dynamic Desktop Protocol (DDP), vCloudPoint zero clients deliver a seamless desktop experience to end users. Whether you are launching applications, scrolling through webpages, editing documents or playing high-definition videos, in the lightweight Window 7 or the fancy Window 10, in a low display resolution of 1366*768 or a high resolution of 1920*1080, you will be having an indistinguishable experience from running on a PC desktop.

Smooth Desktop Experience

Powered by vCloudPoint’s innovative Dynamic Desktop Protocol (DDP), vCloudPoint zero clients deliver a seamless desktop experience to end users. Whether you are launching applications, scrolling through webpages, editing documents or playing high-definition videos, in the lightweight Window 7 or the fancy Window 10, in a low display resolution of 1366*768 or a high resolution of 1920*1080, you will be having an indistinguishable experience from running on a PC desktop.

Excellent Image Quality

With other technologies, image quality must be diminished so that optimal bandwidth and performance can be maintained. With vCloudPoint zero clients, users do not have to sacrifice image quality for high performance and low network bandwidth usage. IT administrators can choose their level of compression, lossy or lossless, based on their network constraints and the needs of end users.

Excellent Image Quality

With other technologies, image quality must be diminished so that optimal bandwidth and performance can be maintained. With vCloudPoint zero clients, users do not have to sacrifice image quality for high performance and low network bandwidth usage. IT administrators can choose their level of compression, lossy or lossless, based on their network constraints and the needs of end users.

Real-Time Audio

vCloudPoint zero clients are capable of supporting real-time audio devices like headsets and microphones with vCloudPoint Virtual Audio Drivers running inside virtual desktops. The vCloudPoint Virtual Audio Drivers are available through the installation of vMatrix Server Manager or Virspire Desktop Agent. These Virtual Audio drivers enable reliable audio playing and recording in any Windows systems and CD-quality sound at the zero clients.

*Sample audio recorded with a vCloudpoint Zero Client Device

16bits

( 16 bits ) depth

48Khz

( 44.1 / 48Khz ) sample rate

100ms

( 0.1 sec ) delay

Real-Time Audio

vCloudPoint zero clients are capable of supporting real-time audio devices like headsets and microphones with vCloudPoint Virtual Audio Drivers running inside virtual desktops. The vCloudPoint Virtual Audio Drivers are available through the installation of vMatrix Server Manager or Virspire Desktop Agent. These Virtual Audio drivers enable reliable audio playing and recording in any Windows systems and CD-quality sound at the zero clients.

*Sample audio recorded with
a vCloudpoint Zero Client Device

Broad USB Device Support

vCloudPoint zero clients support a wide range of USB devices including memory devices, USB hubs, single, multi-functional & dot matrix printers, card reader, office& POS scanners, single touch screens, U keys, and USB converters. USB peripherals never require specialized client drivers to work – just a native Windows driver is required. These USB devices are compatible and reliable with all Windows systems that whenever and however you attach them to the zero clients, they are fully functional as working on the host side.

Broad USB Device Support

vCloudPoint zero clients support a wide range of USB devices including memory devices, USB hubs, single, multi-functional & dot matrix printers, card reader, office& POS scanners, single touch screens, U keys, and USB converters. USB peripherals never require specialized client drivers to work – just a native Windows driver is required. These USB devices are compatible and reliable with all Windows systems that whenever and however you attach them to the zero clients, they are fully functional as working on the host side.

Comparison

S100

  • 1
    Power/ Reset Button
  • 2
    USB2.0
  • 3
    3.5mm Speaker
  • 4
    3.5mm Microphone
  • 5
    10/100 Mbps Ethernet
  • 6
    USB2.0
  • 7
    VGA Display Port
  • 8
    5V DC Power Input

V1

  • 1
    VGA Display Port
  • 2
    HDMI Display Port
  • 3
    10/100/1000 Mbps Ethernet
  • 4
    5V DC Power Input
  • 5
    USB2.0
  • 6
    3.5mm Speaker
  • 7
    3.5mm Microphone
  • 8
    USB 2.0
  • 9
    Power/ Reset Button

How to use the vCloudpoint Zero Client Device

The installation of the vCloudPoint zero client is easy. Simply connect the zero client to the necessary peripherals, and you are ready to access to a virtual desktop with given user credentials. Depending on your back-end infrastructure, there are some installations and configurations needed to be done at the server side.

RDS with vMatrix

1 OS for many users

VDI with Virspire

1 OS for 1 user

Zero clients offer nothing locally but just enable users to connect to a remote desktop. In other words, the residing hardware of a zero client does not act on jobs of processing locally, but only to initialize a conversation with the network, begin network protocol processes, and display desktop output. Therefore, the configuration of a zero client itself does not contribute to the remote desktop performance. There are a few aspects help with good performance of the remote desktop: well-configured host, low latency & high-bandwidth network, and high efficient remote display protocol. Of the above 3 aspects, only the display protocol is determined by the zero clients. vCloudPoint zero clients utilized our innovative DDP (Dynamic Desktop Protocol) for remote desktop display. This protocol is purpose-built for zero clients and is designed to make efficient use of the network bandwidth and host resources, delivering a user experience that is indistinguishable from running on a PC. With DDP, vCloudPoint zero client users can edit documents, chat on IM, write emails, browse websites, enjoy songs& movies, handle graphic designs and use USB　devices as they do on a regular PC.

USB devices that are tested to work on the vCloudPoint zero clients:

Storage Devices, USB Hubs, Single, Multi-functional & Dot Matrix Printers，Smart Card Reader, Office &
POS Scanners, Single Touch Screens, U keys, Parallel to USB Converters, etc; An external power supply
may be required for devices working on large voltage.

Click to download the list of  tested USB devices ; other USB devices that are not listed but functions in the same way are supposed to be supported as well.

Using USB devices with vCloudPoint zero clients:

To use USB devices with vCloudPoint zero clients, you simply installed the native device driver on the host system as you normally do when using PCs. NO extra drivers are required for the zero clients. vCloudPoint USB redirection technology allows USB devices to work on the zero clients as well as on the host.

Printing devices and storage connected to shared host can be accessed by all client users. Printing devices connected to the zero client can be accessed by all other users but storage devices connected to the zero client can be accessed to the current user only due to vCloudPoint’s vCell User Isolation technology.

You can connect the zero clients through wireless network by attaching a compatible external USB antenna to it. There are two ways for you to get the external USB antenna.

1, You can purchase the external USB antenna from your local vCloudPoint dealer.

2, Any antenna that is built with RTL8188EUS chip and connects with USB 2.0 standard is supported by vCloudPoint zero clients.

Given blow is the specification of the external USB antenna:

Connection USB2.0
Chip RTL8188EUS
Antenna External 5dBi antenna
Antenna standard IEEE 802.11g
IEEE 802.11b
IEEE 802.11n
Speed 11b:1/2/5.5/11 Mbps
11g:6/9/12/18/24/36/48/54 Mbps
11n: up to 150 Mbps
Distance up to 200 meters indoor
Frequency range 2.4~2.4835GHZ
Working channel 1~14
Security features WPA-PSK/WPA2-PSK
WPA/WPA2
64/128/152bit WEP encryption
Power 2.5W


Steps to configure external WIFI:

1, attach the USB antenna to the zero client;

2, reboot the zero client;

3, go to the “Network” page and you will see the WIFI option coming. See pictures below.

(the WIFI option will automatically display on Network page once the WIFI module is detected on device boot.)

Note: although vCloudPoint offers a wireless option, customers are strongly recommended to use vCloudPoint zero clients with wired connection, as user experience may significantly compromised due to the unreliable and high latency of most wireless network.
