Synology DiskStation DS225+

Synology DiskStation DS225+

Short Description

  • 1 x 1GbE RJ-45, 1 x 2.5 GbE RJ-45
  • Btrfs file system support
  • Upgradable memory capacity

Available on backorder

Be the first to leave a review.

Description

Hardware Specifications
CPU
 CPU Model Intel Celeron J4125
CPU Quantity 1
CPU Cores 4
CPU Threads 4
CPU Architecture 64-bit
CPU Frequency 2.0 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine
Memory
 System Memory 2 GB DDR4 non-ECC
Total Memory Slots 1
Maximum Memory Capacity 6 GB (2 GB + 4 GB)
Notes
  • Synology may revise pre-installed memory module specifications in response to component lifecycle and supply conditions. All revised components undergo the same rigorous validation to ensure equivalent compatibility, stability, and performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
 Drive Bays (See all supported drives)
2 × 3.5″ SATA HDD or 2.5″ SATA SSD
Hot Swappable Drive*
Notes
  • Synology only guarantees full functionality, reliability, and performance for compatible drives. Please consult our compatibility list before purchasing hard drives. For more details, please refer to this article.
  • SSD cache can be enabled with select compatible SSD. See the compatibility list for model-specific support and details. SSDs are sold separately.
External Ports
 RJ-45 1GbE LAN Port 1
RJ-45 2.5GbE LAN Port 1
USB 3.2 Gen 1 Port 2
USB Copy
Notes MTU value of 1GbE LAN port has a limit of 1500.
Appearance
 Size (Height × Width × Depth) 165 mm × 108 mm × 232.2 mm
Weight 1.3 kg
Others
 System Fan 92 mm × 92 mm × 1 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level 19.6 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 60 watts
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption 16.98 watts (Access)
6.08 watts (HDD Hibernation)
British Thermal Unit 57.90 BTU/hr (Access)
20.73 BTU/hr (HDD Hibernation)
Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
 Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Operating Humidity 8% to 80% RH
Storage Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
  • BIS
Warranty
 3-year hardware warranty, extendable to 5 years with EW201
Notes
  • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
  • EW201/EW202 is only available in Asia, Africa, and Oceania. Refer to the Extended Warranty website for details on supported countries/regions. (Learn more)
Environment
 RoHS Compliant
Packaging Content
  • Main Unit × 1
  • Accessory Pack × 1
  • AC Power Adapter × 1
  • AC Power Cord × 1
  • RJ-45 LAN Cable × 2
Optional Accessories

Reviews

There are no reviews yet.

Be the first to review “Synology DiskStation DS225+”
