Synology DiskStation DS2422+

Synology DiskStation DS2422+

Short Description

  • AMD Ryzen V1500B quad-core 2.2 GHz CPU
  • 4 built-in M.2 NVMe SSD cache slots
  • Expandable up to 36 drives

Be the first to leave a review.

Description

Hardware Specifications
CPU
 CPU Model AMD Ryzen V1500B
CPU Quantity 1
CPU Cores 4
CPU Threads 8
CPU Architecture 64-bit
CPU Frequency 2.2 GHz
Hardware Encryption Engine
Memory
 System Memory 4 GB DDR4 ECC SODIMM
Memory Module Pre-installed 4 GB (4 GB × 1)
Total Memory Slots 2
Maximum Memory Capacity 32 GB (16 GB x 2)
Notes
  • Synology may revise pre-installed memory module specifications in response to component lifecycle and supply conditions. All revised components undergo the same rigorous validation to ensure equivalent compatibility, stability, and performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • For multi-module memory configurations, all modules must be identical and share the same model number. Check the Product Manual of your Synology product for recommended memory configurations.
Storage
 Drive Bays 12
Maximum Drive Bays with Expansion Unit 24 (DX1222 × 1)
Drive Type (See all supported drives)
  • 3.5″ SATA HDD
  • 2.5″ SATA HDD
  • 2.5″ SATA SSD
Hot Swappable Drive*
Notes Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability.
External Ports
 RJ-45 1GbE LAN Port 4
USB 3.2 Gen 1 Port 2
Expansion Port 1
Expansion Port Type Mini-SAS HD
Notes MTU value of 1GbE LAN port has a limit of 1500.
PCIe
 PCIe Expansion 1 x Gen3 x8 slot (x4 link)
Appearance
 Size (Height x Width x Depth) 270 mm × 300 mm × 340 mm
Weight 9.5 kg
Others
 System Fan 120 mm × 120 mm × 2 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Easy Replacement System Fan
Power Recovery
Noise Level* 25 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 550 watts
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption 73.11 watts (Access)
32.12 watts (HDD Hibernation)
British Thermal Unit 249.63 BTU/hr (Access)
109.67 BTU/hr (HDD Hibernation)
Notes
  • Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
 Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Operating Humidity 8% to 80% RH
Storage Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
  • BIS
  • UL
Warranty
 3-year hardware warranty, extendable to 5 years with Extended Warranty Plus
Notes
  • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
  • Extended Warranty Plus is only available in Europe and North America. Refer to the Extended Warranty Plus website for details on supported countries/regions. (Learn more)
Environment
 RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
